Microcontroller programming

"FabAcademy families"

• AtTiny
• SAMD
• RP2040
• ESP32

AtTiny (412 / 1614 / 3216 / ...)

AtTiny microcontrollers are low-cost and low-power devices suitable for simple embedded applications with limited processing and I/O requirements.

Programming : UPDI (older : ISP)

AtTiny (412 / 1614 / 3216 / ...)

• 8 bits - 1MHz-20Mhz (→ 32MHz overclock)
• Versatile I/O (analog, pwm, i²c, UART, SPI, ...)
• Single pin programming (UPDI)
• Sandbox board : Adrianino

SAMD (11C, 11D, 21E, D51)

SAMD microcontrollers offer a balance of performance and power efficiency, making them suitable for a wide range of applications including IoT devices and wearables.

Programming : SWD / JTAG

SAMD (11C, 11D, 21E, D51)

• 32 bits - 48MHz - Single ARM Cortex-M0+
• Native USB support (+CDC +HID)
• Versatile I/O (analog, pwm, i²c, UART, SPI, ...)
• Sandbox board : Samdino

RP2040

The RP2040, developed by Raspberry Pi, is a dual-core ARM Cortex-M0+ microcontroller with versatile I/O capabilities (PIO!), making it ideal for projects requiring multitasking and connectivity.

Programming : UF2

RP2040

• 32 bits - 133MHz (→ >250MHz overclocking)
• Dual ARM Cortex-M0+
• Hardcoded bootloader - XIAO module or RPi Zero
• Sandbox board : FabXIAO

ESP32-C3/S3

ESP32-C3 and ESP32-S3 are developed by Espressif Systems, known for their built-in Wi-Fi and Bluetooth capabilities.
→ IoT projects requiring wireless connectivity

• RISC-V - 160MHz
• Wifi 4 - BlueTooth 5 (LE)
• Versatile I/O
• Sandbox board : FabXIAO

Others

STM32

PIC (Microchip)

MSP/TI

...

General rule : RTFM / RTFDatasheet

Always refer to the microcontroller's datasheet and reference manual for detailed specifications and usage instructions. These documents provide essential information for programming and configuring the microcontroller.

• ASM / PIO / ...
• C / C++
• Rust
• microPython
• JavaScript
• Go

Assembly / PIO / VHDL / Verilog

Assembly language provides direct control over the microcontroller's hardware, making it efficient but complex to write. Programmable I/O (PIO) offers a way to offload I/O operations from the CPU, enhancing performance in certain scenarios.

Learn binary/logic basics! (worth it!)

C and C++ are widely used for microcontroller programming due to their efficiency and low-level access to hardware. They are compiled languages, meaning the code is translated into machine language before execution.

Note : Arduino is C++ based

Rust is gaining popularity for microcontroller development due to its strong safety guarantees and modern features. Like C and C++, Rust code is compiled before execution.

E.g.Minecraft rendering on RP2040

MicroPython offers a higher level of abstraction compared to C and assembly, making it easier to write and understand code. It can be either interpreted directly or precompiled into bytecode for execution.

JavaScript can be used for microcontroller programming (Kaluma / Esrpuino). It offers a familiar syntax for web developers but typically requires more resources compared to lower-level languages like C.

TinyGo brings the Go language to microcontrollers.

• Various microcontrollers (samd, rp2040, ...)
• Includes optimized garbage collector
• Comes with built-in libraries for GPIO, I2C, SPI, etc.
• Supports cross-compilation for easy development
• Drawback : not fully multi-core compatible (yet?)

Mixed languages

Mixing languages might give you the best of each world. E.g. : ASM → C → C++

Mixing microPython and PIO "assembly" on RP2040

import array, time
import rp2
import machine
NUM_LEDS = 10
BLACK = (0, 0, 0)
RED = (255, 0, 0)
YELLOW = (255, 150, 0)
GREEN = (0, 255, 0)
CYAN = (0, 255, 255)
BLUE = (0, 0, 255)
PURPLE = (180, 0, 255)
WHITE = (255, 255, 255)
COLORS = (BLACK, RED, YELLOW, GREEN, CYAN, BLUE, PURPLE, WHITE)
BRIGHTNESS = 0.1
def setColor(color):
    r = int(color[0]*BRIGHTNESS)
    g = int(color[1]*BRIGHTNESS)
    b = int(color[2]*BRIGHTNESS)
    return (g<<16) + (r<<8) + b

@rp2.asm_pio(set_init=rp2.PIO.OUT_LOW, out_init=rp2.PIO.OUT_LOW, out_shiftdir=rp2.PIO.SHIFT_LEFT, autopull=True, pull_thresh=24)
def ws2812():
    # 1 step = 0.2us (clock frequency must be set to 5MHz)
    wrap_target()
    # 1 step at 0 (to wait for data in low state, reset code)
    out(x, 1)
    # start of the cycle
    # 2 step at 1
    set(pins, 1) [1]
    # 2 step at x
    mov(pins, x) [1]
    # 1 step at 0
    set(pins, 0)
    wrap()
sm = rp2.StateMachine(0, ws2812, freq=5_000_000, set_base=machine.Pin(12), out_base=machine.Pin(12))
sm.active(1)

ar = array.array("I", [0 for _ in range(NUM_LEDS)])

# Set all leds to green
for i in range(NUM_LEDS):
    ar[i] = setColor(GREEN)
sm.put(ar, 8)
time.sleep_ms(50)

# Rotate one red led
cpt = 1
while True:
    ar[cpt-1] = setColor(GREEN)
    ar[cpt] = setColor(RED)
    sm.put(ar, 8)
    time.sleep_ms(50)
    cpt = (cpt+1)%NUM_LEDS
import array, time
import rp2
import machine
NUM_LEDS = 10
BLACK = (0, 0, 0)
RED = (255, 0, 0)
YELLOW = (255, 150, 0)
GREEN = (0, 255, 0)
CYAN = (0, 255, 255)
BLUE = (0, 0, 255)
PURPLE = (180, 0, 255)
WHITE = (255, 255, 255)
COLORS = (BLACK, RED, YELLOW, GREEN, CYAN, BLUE, PURPLE, WHITE)
BRIGHTNESS = 0.1
def setColor(color):
    r = int(color[0]*BRIGHTNESS)
    g = int(color[1]*BRIGHTNESS)
    b = int(color[2]*BRIGHTNESS)
    return (g<<16) + (r<<8) + b

@rp2.asm_pio(set_init=rp2.PIO.OUT_LOW, out_init=rp2.PIO.OUT_LOW, out_shiftdir=rp2.PIO.SHIFT_LEFT, autopull=True, pull_thresh=24)
def ws2812():
    # 1 step = 0.2us (clock frequency must be set to 5MHz)
    wrap_target()
    # 1 step at 0 (to wait for data in low state, reset code)
    out(x, 1)
    # start of the cycle
    # 2 step at 1
    set(pins, 1) [1]
    # 2 step at x
    mov(pins, x) [1]
    # 1 step at 0
    set(pins, 0)
    wrap()
sm = rp2.StateMachine(0, ws2812, freq=5_000_000, set_base=machine.Pin(12), out_base=machine.Pin(12))
sm.active(1)

ar = array.array("I", [0 for _ in range(NUM_LEDS)])

# Set all leds to green
for i in range(NUM_LEDS):
    ar[i] = setColor(GREEN)
sm.put(ar, 8)
time.sleep_ms(50)

# Rotate one red led
cpt = 1
while True:
    ar[cpt-1] = setColor(GREEN)
    ar[cpt] = setColor(RED)
    sm.put(ar, 8)
    time.sleep_ms(50)
    cpt = (cpt+1)%NUM_LEDS
import array, time
import rp2
import machine
NUM_LEDS = 10
BLACK = (0, 0, 0)
RED = (255, 0, 0)
YELLOW = (255, 150, 0)
GREEN = (0, 255, 0)
CYAN = (0, 255, 255)
BLUE = (0, 0, 255)
PURPLE = (180, 0, 255)
WHITE = (255, 255, 255)
COLORS = (BLACK, RED, YELLOW, GREEN, CYAN, BLUE, PURPLE, WHITE)
BRIGHTNESS = 0.1
def setColor(color):
    r = int(color[0]*BRIGHTNESS)
    g = int(color[1]*BRIGHTNESS)
    b = int(color[2]*BRIGHTNESS)
    return (g<<16) + (r<<8) + b

@rp2.asm_pio(set_init=rp2.PIO.OUT_LOW, out_init=rp2.PIO.OUT_LOW, out_shiftdir=rp2.PIO.SHIFT_LEFT, autopull=True, pull_thresh=24)
def ws2812():
    # 1 step = 0.2us (clock frequency must be set to 5MHz)
    wrap_target()
    # 1 step at 0 (to wait for data in low state, reset code)
    out(x, 1)
    # start of the cycle
    # 2 step at 1
    set(pins, 1) [1]
    # 2 step at x
    mov(pins, x) [1]
    # 1 step at 0
    set(pins, 0)
    wrap()
sm = rp2.StateMachine(0, ws2812, freq=5_000_000, set_base=machine.Pin(12), out_base=machine.Pin(12))
sm.active(1)

ar = array.array("I", [0 for _ in range(NUM_LEDS)])

# Set all leds to green
for i in range(NUM_LEDS):
    ar[i] = setColor(GREEN)
sm.put(ar, 8)
time.sleep_ms(50)

# Rotate one red led
cpt = 1
while True:
    ar[cpt-1] = setColor(GREEN)
    ar[cpt] = setColor(RED)
    sm.put(ar, 8)
    time.sleep_ms(50)
    cpt = (cpt+1)%NUM_LEDS

Bootloader : small program stored memory that initialize the µC and load/rewrite code from a secondary storage device such as serial port (USB/UART), flash memory or EEPROM.

Hardcoded bootloader (UF2)

Hardcoded bootloaders like UF2 provide a convenient way to load firmware onto a microcontroller without requiring a separate programming tool. They are often used in development boards and single-board computers. (e.g. : XIAO2040)

One programmer to rule them all

Basic board for using Alex Tardov's Free DAP

Arduino Uno = board = hardware

The Arduino Uno refers to a specific hardware board featuring an Atmel ATmega328P microcontroller. It is (was?) one of the most commonly used Arduino boards for prototyping and educational purposes.

Arduino is a set of libraries

Arduino provides a rich set of libraries that simplify common tasks such as reading analog inputs, controlling digital outputs, and communicating with peripherals like sensors and displays.

• Let you write code without knowing all the registers details and in a portable (various chips) way.
• Generated code usually (much) less efficient.

"Pure C" VS Arduino

//
// ring.t412.ino
//
// ATtiny412 ring oscillator test
//
// Neil Gershenfeld 11/13/20
//
// This work may be reproduced, modified, distributed,
// performed, and displayed for any purpose, but must
// acknowledge this project. Copyright is retained and
// must be preserved. The work is provided as is; no
// warranty is provided, and users accept all liability.
//

void setup() {
   CPU_CCP = CCP_IOREG_gc; // unprotect clock
   CLKCTRL.MCLKCTRLB = 0; // turn off prescalar (20 MHz)
   PORTA.DIRSET = PIN6_bm; // set output pin
   }

void loop() {
   while(1) {
      //
      // VPORT: 1.808 MHz
      //    250 ns high (5 cycles), 300 ns low (6 cycles)
      //
      if (VPORTA.IN & PIN7_bm)
         VPORTA.OUT &= ~PIN6_bm;
      else
         VPORTA.OUT |= PIN6_bm;
      //
      // PORT: 1.056 MHz
      //
      /*
      if (PORTA.IN & PIN7_bm)
         PORTA.OUTCLR = PIN6_bm;
      else
         PORTA.OUTSET = PIN6_bm;
      */
      //
      // digitalRead/Write: 0.331 MHz
      //
      //*
      if (digitalRead(1))
         digitalWrite(0,LOW);
      else
         digitalWrite(0,HIGH);
      */
      //
      // digitalReadFast/WriteFast: 1.808 MHz
      //
      /*
      if (digitalReadFast(1))
         digitalWriteFast(0,LOW);
      else
         digitalWriteFast(0,HIGH);
      */
      }
   }
//
// ring.t412.ino
//
// ATtiny412 ring oscillator test
//
// Neil Gershenfeld 11/13/20
//
// This work may be reproduced, modified, distributed,
// performed, and displayed for any purpose, but must
// acknowledge this project. Copyright is retained and
// must be preserved. The work is provided as is; no
// warranty is provided, and users accept all liability.
//

void setup() {
   CPU_CCP = CCP_IOREG_gc; // unprotect clock
   CLKCTRL.MCLKCTRLB = 0; // turn off prescalar (20 MHz)
   PORTA.DIRSET = PIN6_bm; // set output pin
   }

void loop() {
   while(1) {
      //
      // VPORT: 1.808 MHz
      //    250 ns high (5 cycles), 300 ns low (6 cycles)
      //
      if (VPORTA.IN & PIN7_bm)
         VPORTA.OUT &= ~PIN6_bm;
      else
         VPORTA.OUT |= PIN6_bm;
      //
      // PORT: 1.056 MHz
      //
      /*
      if (PORTA.IN & PIN7_bm)
         PORTA.OUTCLR = PIN6_bm;
      else
         PORTA.OUTSET = PIN6_bm;
      */
      //
      // digitalRead/Write: 0.331 MHz
      //
      //*
      if (digitalRead(1))
         digitalWrite(0,LOW);
      else
         digitalWrite(0,HIGH);
      */
      //
      // digitalReadFast/WriteFast: 1.808 MHz
      //
      /*
      if (digitalReadFast(1))
         digitalWriteFast(0,LOW);
      else
         digitalWriteFast(0,HIGH);
      */
      }
   }
//
// ring.t412.ino
//
// ATtiny412 ring oscillator test
//
// Neil Gershenfeld 11/13/20
//
// This work may be reproduced, modified, distributed,
// performed, and displayed for any purpose, but must
// acknowledge this project. Copyright is retained and
// must be preserved. The work is provided as is; no
// warranty is provided, and users accept all liability.
//

void setup() {
   CPU_CCP = CCP_IOREG_gc; // unprotect clock
   CLKCTRL.MCLKCTRLB = 0; // turn off prescalar (20 MHz)
   PORTA.DIRSET = PIN6_bm; // set output pin
   }

void loop() {
   while(1) {
      //
      // VPORT: 1.808 MHz
      //    250 ns high (5 cycles), 300 ns low (6 cycles)
      //
      if (VPORTA.IN & PIN7_bm)
         VPORTA.OUT &= ~PIN6_bm;
      else
         VPORTA.OUT |= PIN6_bm;
      //
      // PORT: 1.056 MHz
      //
      /*
      if (PORTA.IN & PIN7_bm)
         PORTA.OUTCLR = PIN6_bm;
      else
         PORTA.OUTSET = PIN6_bm;
      */
      //
      // digitalRead/Write: 0.331 MHz
      //
      //*
      if (digitalRead(1))
         digitalWrite(0,LOW);
      else
         digitalWrite(0,HIGH);
      */
      //
      // digitalReadFast/WriteFast: 1.808 MHz
      //
      /*
      if (digitalReadFast(1))
         digitalWriteFast(0,LOW);
      else
         digitalWriteFast(0,HIGH);
      */
      }
   }

• AtTiny : Spence Konde
• SAMD : MattairTech. Fork Fab maintainted (QB fork)
• Rp2040 : Earle F. Philhower porting
• ESP32 : Espressif
• ...

Arduino IDE is a development environment

The Arduino Integrated Development Environment (IDE) is a software tool used for writing, compiling, and uploading code to Arduino boards. It includes features like syntax highlighting, serial monitor, and library management.

Be aware :

• IDE v2 has a better editor BUT has compatibility issues with some libraries (AtTiny port!)
• IDE v1.9 and above works fine but less user friendly (use external editor... [preferences > ])

Fit-for-purpose processor

Selecting a microcontroller with appropriate processing power for your application can help conserve energy and reduce cost. Underclocking, or running the microcontroller at a lower frequency, may be beneficial for power-sensitive projects.

Underclocking may be as usefull as overclocking!

Write modular and readable

Breaking down your code into modular components enhances readability and maintainability. Organize your code into separate functions or modules based on their functionality to facilitate debugging and future updates.

Flat files are difficult to modify / maintain.

Modular writing

// Flat File: Single File

...

void loop() {
  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);
  delay(200); // Wait for 200ms

  // Turn off the LED
  digitalWrite(LED_PIN, LOW);
  delay(1000); // Wait for 1 second

  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);
  delay(400); // Wait for 400ms

  // Turn off the LED
  digitalWrite(LED_PIN, LOW);
  delay(2000); // Wait for 2 second
}


// Modular writing :

void flipAndWait(uint8_t pin, unsigned long time){
  digitalWrite(pin, !digitalRead(pin));
  delay(time);
}

void loop() {
  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);  //set LED high
  delay(200);                   // Wait for 1 second

  flipAndWait(LED_PIN, 1000);   //flip and wait for 1sec
  flipAndWait(LED_PIN, 400);    //flip and wait for 400ms
  flipAndWait(LED_PIN, 2000);   //flip and wait for 2sec
}
// Flat File: Single File

...

void loop() {
  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);
  delay(200); // Wait for 200ms

  // Turn off the LED
  digitalWrite(LED_PIN, LOW);
  delay(1000); // Wait for 1 second

  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);
  delay(400); // Wait for 400ms

  // Turn off the LED
  digitalWrite(LED_PIN, LOW);
  delay(2000); // Wait for 2 second
}


// Modular writing :

void flipAndWait(uint8_t pin, unsigned long time){
  digitalWrite(pin, !digitalRead(pin));
  delay(time);
}

void loop() {
  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);  //set LED high
  delay(200);                   // Wait for 1 second

  flipAndWait(LED_PIN, 1000);   //flip and wait for 1sec
  flipAndWait(LED_PIN, 400);    //flip and wait for 400ms
  flipAndWait(LED_PIN, 2000);   //flip and wait for 2sec
}
// Flat File: Single File

...

void loop() {
  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);
  delay(200); // Wait for 200ms

  // Turn off the LED
  digitalWrite(LED_PIN, LOW);
  delay(1000); // Wait for 1 second

  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);
  delay(400); // Wait for 400ms

  // Turn off the LED
  digitalWrite(LED_PIN, LOW);
  delay(2000); // Wait for 2 second
}


// Modular writing :

void flipAndWait(uint8_t pin, unsigned long time){
  digitalWrite(pin, !digitalRead(pin));
  delay(time);
}

void loop() {
  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);  //set LED high
  delay(200);                   // Wait for 1 second

  flipAndWait(LED_PIN, 1000);   //flip and wait for 1sec
  flipAndWait(LED_PIN, 400);    //flip and wait for 400ms
  flipAndWait(LED_PIN, 2000);   //flip and wait for 2sec
}
// Flat File: Single File

...

void loop() {
  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);
  delay(200); // Wait for 200ms

  // Turn off the LED
  digitalWrite(LED_PIN, LOW);
  delay(1000); // Wait for 1 second

  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);
  delay(400); // Wait for 400ms

  // Turn off the LED
  digitalWrite(LED_PIN, LOW);
  delay(2000); // Wait for 2 second
}


// Modular writing :

void flipAndWait(uint8_t pin, unsigned long time){
  digitalWrite(pin, !digitalRead(pin));
  delay(time);
}

void loop() {
  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);  //set LED high
  delay(200);                   // Wait for 1 second

  flipAndWait(LED_PIN, 1000);   //flip and wait for 1sec
  flipAndWait(LED_PIN, 400);    //flip and wait for 400ms
  flipAndWait(LED_PIN, 2000);   //flip and wait for 2sec
}
// Flat File: Single File

...

void loop() {
  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);
  delay(200); // Wait for 200ms

  // Turn off the LED
  digitalWrite(LED_PIN, LOW);
  delay(1000); // Wait for 1 second

  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);
  delay(400); // Wait for 400ms

  // Turn off the LED
  digitalWrite(LED_PIN, LOW);
  delay(2000); // Wait for 2 second
}


// Modular writing :

void flipAndWait(uint8_t pin, unsigned long time){
  digitalWrite(pin, !digitalRead(pin));
  delay(time);
}

void loop() {
  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);  //set LED high
  delay(200);                   // Wait for 1 second

  flipAndWait(LED_PIN, 1000);   //flip and wait for 1sec
  flipAndWait(LED_PIN, 400);    //flip and wait for 400ms
  flipAndWait(LED_PIN, 2000);   //flip and wait for 2sec
}
// Flat File: Single File

...

void loop() {
  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);
  delay(200); // Wait for 200ms

  // Turn off the LED
  digitalWrite(LED_PIN, LOW);
  delay(1000); // Wait for 1 second

  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);
  delay(400); // Wait for 400ms

  // Turn off the LED
  digitalWrite(LED_PIN, LOW);
  delay(2000); // Wait for 2 second
}


// Modular writing :

void flipAndWait(uint8_t pin, unsigned long time){
  digitalWrite(pin, !digitalRead(pin));
  delay(time);
}

void loop() {
  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);  //set LED high
  delay(200);                   // Wait for 1 second

  flipAndWait(LED_PIN, 1000);   //flip and wait for 1sec
  flipAndWait(LED_PIN, 400);    //flip and wait for 400ms
  flipAndWait(LED_PIN, 2000);   //flip and wait for 2sec
}
// Flat File: Single File

...

void loop() {
  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);
  delay(200); // Wait for 200ms

  // Turn off the LED
  digitalWrite(LED_PIN, LOW);
  delay(1000); // Wait for 1 second

  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);
  delay(400); // Wait for 400ms

  // Turn off the LED
  digitalWrite(LED_PIN, LOW);
  delay(2000); // Wait for 2 second
}


// Modular writing :

void flipAndWait(uint8_t pin, unsigned long time){
  digitalWrite(pin, !digitalRead(pin));
  delay(time);
}

void loop() {
  // Turn on the LED
  digitalWrite(LED_PIN, HIGH);  //set LED high
  delay(200);                   // Wait for 1 second

  flipAndWait(LED_PIN, 1000);   //flip and wait for 1sec
  flipAndWait(LED_PIN, 400);    //flip and wait for 400ms
  flipAndWait(LED_PIN, 2000);   //flip and wait for 2sec
}

Write "parametric"

const / #DEFINE

Avoid constants/values directly into your code
→ use symbolic names or macros defined with const variables or #define directives.

This improves code clarity and allows for easier modifications in the future.

Parametric : Example

// the setup function runs once when you press reset or power the board
void setup()
{
  // initialize digital pin (led connected to pin7) as an output.
  pinMode(7, OUTPUT);
}

// the loop function runs over and over again forever
void loop()
{
  digitalWrite(7, HIGH); // turn the LED on (HIGH is the voltage level)
  delay(200);            // flash for 200ms
  digitalWrite(7, LOW);  // turn the LED off by making the voltage LOW
  delay(800);            // wait for 800ms (total = ~1sec)
}
// the setup function runs once when you press reset or power the board
void setup()
{
  // initialize digital pin (led connected to pin7) as an output.
  pinMode(7, OUTPUT);
}

// the loop function runs over and over again forever
void loop()
{
  digitalWrite(7, HIGH); // turn the LED on (HIGH is the voltage level)
  delay(200);            // flash for 200ms
  digitalWrite(7, LOW);  // turn the LED off by making the voltage LOW
  delay(800);            // wait for 800ms (total = ~1sec)
}
// the setup function runs once when you press reset or power the board
void setup()
{
  // initialize digital pin (led connected to pin7) as an output.
  pinMode(7, OUTPUT);
}

// the loop function runs over and over again forever
void loop()
{
  digitalWrite(7, HIGH); // turn the LED on (HIGH is the voltage level)
  delay(200);            // flash for 200ms
  digitalWrite(7, LOW);  // turn the LED off by making the voltage LOW
  delay(800);            // wait for 800ms (total = ~1sec)
}

Parametric : Example

#define LED          7
#define PERIOD    1000
#define FLASH_TIME 200
// the setup function runs once when you press reset or power the board
void setup()
{
  // initialize digital pin LED as an output.
  pinMode(LED, OUTPUT);
}

// the loop function runs over and over again forever
void loop()
{
  digitalWrite(LED, HIGH); // turn the LED on (HIGH is the voltage level)
  delay(FLASH_TIME);               // wait for a ON_TIME
  digitalWrite(LED, LOW);  // turn the LED off by making the voltage LOW
  delay(PERIOD-FLASH_TIME);        // wait to get a periodic time of ~PERIOD
}
#define LED          7
#define PERIOD    1000
#define FLASH_TIME 200
// the setup function runs once when you press reset or power the board
void setup()
{
  // initialize digital pin LED as an output.
  pinMode(LED, OUTPUT);
}

// the loop function runs over and over again forever
void loop()
{
  digitalWrite(LED, HIGH); // turn the LED on (HIGH is the voltage level)
  delay(FLASH_TIME);               // wait for a ON_TIME
  digitalWrite(LED, LOW);  // turn the LED off by making the voltage LOW
  delay(PERIOD-FLASH_TIME);        // wait to get a periodic time of ~PERIOD
}
#define LED          7
#define PERIOD    1000
#define FLASH_TIME 200
// the setup function runs once when you press reset or power the board
void setup()
{
  // initialize digital pin LED as an output.
  pinMode(LED, OUTPUT);
}

// the loop function runs over and over again forever
void loop()
{
  digitalWrite(LED, HIGH); // turn the LED on (HIGH is the voltage level)
  delay(FLASH_TIME);               // wait for a ON_TIME
  digitalWrite(LED, LOW);  // turn the LED off by making the voltage LOW
  delay(PERIOD-FLASH_TIME);        // wait to get a periodic time of ~PERIOD
}
#define LED          7
#define PERIOD    1000
#define FLASH_TIME 200
// the setup function runs once when you press reset or power the board
void setup()
{
  // initialize digital pin LED as an output.
  pinMode(LED, OUTPUT);
}

// the loop function runs over and over again forever
void loop()
{
  digitalWrite(LED, HIGH); // turn the LED on (HIGH is the voltage level)
  delay(FLASH_TIME);               // wait for a ON_TIME
  digitalWrite(LED, LOW);  // turn the LED off by making the voltage LOW
  delay(PERIOD-FLASH_TIME);        // wait to get a periodic time of ~PERIOD
}

Use Classes

Class:

• Allows you to "think as objects"
• Is called "object oriented" (C++ vs C)
• Widely used by Arduino hardware specific libraries

Classes

// Definition of the LEDControl class
class LEDControl {
  private:
    int pin; // Class variable to store the pin number

  public:
    // Constructor of the class to initialize the pin
    LEDControl(int pinNumber) {
      pin = pinNumber;
      pinMode(pin, OUTPUT);
    }

    // Method to turn on the LED
    void turnOn() {
      digitalWrite(pin, HIGH);
    }

    // Method to turn off the LED
    void turnOff() {
      digitalWrite(pin, LOW);
    }

    // Method to toggle the state of the LED
    void toggle() {
      digitalWrite(pin, !digitalRead(pin));
    }

    // Method to flash the LED for a specified time
    void flash(int flashTime) {
      turnOn(); // Turn on the LED
      delay(flashTime); // Wait for the specified time
      turnOff(); // Turn off the LED
    }
};

// Using the LEDControl class
const int LED_PIN = 13; // LED pin number

void setup() {
  // Create an instance of LEDControl with pin 13
  LEDControl myLED(LED_PIN);
}

void loop() {
  // Turn on the LED for 1 second
  myLED.flash(200);
  delay(1000);
}
// Definition of the LEDControl class
class LEDControl {
  private:
    int pin; // Class variable to store the pin number

  public:
    // Constructor of the class to initialize the pin
    LEDControl(int pinNumber) {
      pin = pinNumber;
      pinMode(pin, OUTPUT);
    }

    // Method to turn on the LED
    void turnOn() {
      digitalWrite(pin, HIGH);
    }

    // Method to turn off the LED
    void turnOff() {
      digitalWrite(pin, LOW);
    }

    // Method to toggle the state of the LED
    void toggle() {
      digitalWrite(pin, !digitalRead(pin));
    }

    // Method to flash the LED for a specified time
    void flash(int flashTime) {
      turnOn(); // Turn on the LED
      delay(flashTime); // Wait for the specified time
      turnOff(); // Turn off the LED
    }
};

// Using the LEDControl class
const int LED_PIN = 13; // LED pin number

void setup() {
  // Create an instance of LEDControl with pin 13
  LEDControl myLED(LED_PIN);
}

void loop() {
  // Turn on the LED for 1 second
  myLED.flash(200);
  delay(1000);
}
// Definition of the LEDControl class
class LEDControl {
  private:
    int pin; // Class variable to store the pin number

  public:
    // Constructor of the class to initialize the pin
    LEDControl(int pinNumber) {
      pin = pinNumber;
      pinMode(pin, OUTPUT);
    }

    // Method to turn on the LED
    void turnOn() {
      digitalWrite(pin, HIGH);
    }

    // Method to turn off the LED
    void turnOff() {
      digitalWrite(pin, LOW);
    }

    // Method to toggle the state of the LED
    void toggle() {
      digitalWrite(pin, !digitalRead(pin));
    }

    // Method to flash the LED for a specified time
    void flash(int flashTime) {
      turnOn(); // Turn on the LED
      delay(flashTime); // Wait for the specified time
      turnOff(); // Turn off the LED
    }
};

// Using the LEDControl class
const int LED_PIN = 13; // LED pin number

void setup() {
  // Create an instance of LEDControl with pin 13
  LEDControl myLED(LED_PIN);
}

void loop() {
  // Turn on the LED for 1 second
  myLED.flash(200);
  delay(1000);
}
// Definition of the LEDControl class
class LEDControl {
  private:
    int pin; // Class variable to store the pin number

  public:
    // Constructor of the class to initialize the pin
    LEDControl(int pinNumber) {
      pin = pinNumber;
      pinMode(pin, OUTPUT);
    }

    // Method to turn on the LED
    void turnOn() {
      digitalWrite(pin, HIGH);
    }

    // Method to turn off the LED
    void turnOff() {
      digitalWrite(pin, LOW);
    }

    // Method to toggle the state of the LED
    void toggle() {
      digitalWrite(pin, !digitalRead(pin));
    }

    // Method to flash the LED for a specified time
    void flash(int flashTime) {
      turnOn(); // Turn on the LED
      delay(flashTime); // Wait for the specified time
      turnOff(); // Turn off the LED
    }
};

// Using the LEDControl class
const int LED_PIN = 13; // LED pin number

void setup() {
  // Create an instance of LEDControl with pin 13
  LEDControl myLED(LED_PIN);
}

void loop() {
  // Turn on the LED for 1 second
  myLED.flash(200);
  delay(1000);
}

Optimizations

Some tips :

• lookup tables (vs complex maths)
• inline
• pointers
• "simple" arithmetics : 2ⁿ divisions = >>
• Proper type : uint8_t, int16_t, etc. (pecularly on 8bits proc)
• ...

Write down what you do

The Pragmatic Programmer

Talk to me

Narrowing down the problem

• Reproduce the problem

• Reproduce the problem
• Always first do visual check

• Reproduce the problem
• Always first do visual check
traces
soldering
components

• Reproduce the problem
• Always first do visual check
traces
soldering
components
• Keep in mind that the problem
  might not be visible without a microscope

Continuity

• Test power supply to power pins continuity
• Check fuses, diodes orientations, ...
• Check short-circuits
• Check traces

• Parallel measurement => check your cables!
• ! absolute maximum ratings (may burn your component)
• Power supply impedence / max power, badly selected
• GND/VCC loop

Continuity

Voltage drop

Logic Analayzer

• "logic analyzer 8 channel"
• "logic analyzer 16 channel"
• "Digikey 461-1010-ND: MICRO-HOOK RED 0.025" SQ PINS"
• "Digikey 461-1010-ND: MICRO-HOOK BLACK 0.025" SQ PINS"

Miniware LA104

LA104 and alternative firmware and apps

USB

SWD/JTag

UPDI

Unified Program and Debug Interface

Serial (or any) "Hello world!"


#define DEBUG_MODE 1
	...
#if DEBUG_MODE
	 Serial.print("DEBUG -- MyVal value = ");
	Serial.println(MyVal, DEC);
#endif

#define DEBUG_MODE 1
	...
#if DEBUG_MODE
	 Serial.print("DEBUG -- MyVal value = ");
	Serial.println(MyVal, DEC);
#endif
