💧 The Start of the End
The objective of this week is to establish the basic tools—both in terms of materials and knowledge—needed to successfully carry out the development of the final project. To achieve this, we will set certain guidelines starting from the project's concept up to its current stage of development.
💧 Design Concept
To select the best set of components and the necessary knowledge for the project, it is proposed to explain how the device works.
💧 CAD Design
The project was modeled at the component level for fabrication and was entirely designed in Rhinoceros.
💧 System Design
The functional process of the project is explained in the following diagram.
💧 PCB Design
The PCB design was developed in the electronics section of Autodesk Fusion.
💧 Packaging Design
lightweight cardboard packaging is proposed to leverage the machine's portability and low weight. The equipment's legs fold to fit into a rectangular compartment, with strategically placed holes to utilize the machine's handle, transforming the packaging into an easily transportable element.
