Final Project: Planning¶
Sketch¶
This is the design sketch of the bird feeder, showing its structure and key features like food storage, waste collection, and electronics.
User Interaction¶
- Users can refill the feed storage from the top, which is covered to prevent contamination.
- LED indicators provide real-time feedback on food levels
- The feeder can be mounted in multiple ways depending on user preference—standing or hanging
Component List¶
| Component | Function |
|---|---|
| ESP32 / RP2040 | Microcontroller for processing and connectivity |
| Microphone module | Captures bird sounds for interaction |
| Food level sensor | Detects when food is running low (Ultrasonic / Weight sensor) |
| Vibration motor / Servo motor | Enables self-cleaning mechanism |
| PCB (custom milled) | Integrates all circuit components |
| LED indicators | Signals food level or activity |
| OLED Display | Displays bird species detected (?) |
